| Burner Ratings |
| Right Front Surface Element Rating: |
240V - 1800 Watts, 208V - 1560 Watts |
| Right Rear Surface Element Rating: |
240V - 3300 Watts, 208V - 2800 Watts |
| Center Front Surface Element Rating: |
240V - 1800 Watts, 208V - 1350 Watts |
| Bridge Surface Element Rating: |
240V - 800 Watts, 208V - 600 Watts |
| Center Rear Surface Element Rating: |
240V - 1800 Watts, 208V - 1350 Watts |
| Left Front Surface Element Rating: |
240V - 2200 Watts, 208V - 1650 Watts |
| Left Rear Surface Element Rating: |
240V - 1500 Watts, 208V - 1125 Watts |
| Others |
| Electrical Requirements: |
240 - 208/120 VAC/60 Hz - 3-Wire Conduit with a No. 10 Ground Wire. |
| Maximum Amp Usage: |
240V 13.2 kW; 55.0 Amps, 208V 10.4 kW; 50.2 Amps |
| Approximate Shipping Weight: |
63 Lbs. (28.4 kg) |
| Overall Dimensions |
| Overall Width: |
36 3/4" (93.3 cm) |
| Overall Height from Bottom: |
6 3/4" (17.2 cm) |
| Overall Depth from Rear: |
21" (53.3 cm) |
| Cutout Dimensions |
| Cutout Width: |
34 9/16" (87.8 cm) to 35 1/2" (90.2 cm) |
| Cutout Depth: |
19 1/8" (48.6 cm) to 19 7/8" (50.5 cm) |
